PTFE Coated Fiber Glass Fabrics
PTFE it self is a highly versatile product with well know remarkable properties and fiberglass is well known as an excellent material in terms of its high temperature resistance and dimensionally stability. Combination of these two materials gives one product of practically unsurpassed utility and value with following properties:
Properties
- High release from sticky materials 'Non stick' smooth surface
- Operating temperature range -50”ĘC to +260”ĘC
- Excellent chemical resistance
- High electrical insulative and dielectric properties
- Dimensional stabilities under heat and pressure
- Low electrical losses
- Mildew and fungus resistance
- Ultra-Violet, infra-Red, Micro-wave, radio frequency resistance
Selected woven glass fabrics are coated with PTFE resin. It is available with a surface profile that ranges from super smooth with a high PTFE content to one that is textured. It can be produced with a controlled porosity or with special electrical characteristics. It is utilized in sheet form, in slitted rolls, fabricated pieces and as the base material for process conveyor belts.
| Product Style | MC 3NP | MC 5NP | MC 6NP | MC 10NP | MC14NP | MC 22NP | MC 90NP |
| Thickness | 0.08mm | 0.13mm | 0.15mm | 0.25mm | 0.35mm | 0.55mm | 1mm |
| Standard width | 1000mm | ||||||
| Slitted tape width | 12.5mm, | 20mm, | 25mm, | 40mm, | 75mm, | 200mm, | 500mm |
Higher width fabric is also available on request.
